Replacement Hardware Kits for the Original Big Sucker™ Air Cleaner Series. Each hardware kits includes genuine Big Sucker™ hardware and gaskets for Stage 1 Series Intakes

  • Includes necessary hardware & gaskets included with Stage 1 Big Sucker™ Air Cleaners
  • Be sure to choose the proper fitment / application
  • These kits are used for replacement parts or service intervals
  • Fitment: Arlen Ness® Stage 1 Big Sucker™



warning California Prop 65: Learn More
Kit Components (BOM)

602-013 - 17-UP M8 MODELS

Oil Reservoir Gasket: 18-392-4 (1)

Throttle Body Gasket: 18-457-3 (1)

Banjo Bolt: 18-457-4C (2)

Spacer: 18-457-5 (1) For Stock Style Kits Only

Shooter Tubes: BT-001 (2)

Banjo Bolt O-Rings: H-024-4 (4)

Socket Cap: 8-32x5/8 (2) For Round Style Kits Only



602-012 - 2008-2016 FLT / 2016-2017 SOFTAIL & FXDLS (Throttle-By-Wire)

Throttle Body Gasket: 18-500-10 (1)

Breather Bolts: 18-500-10 (2)

O-Rings: H-024-4 (4)

Washers: H-023-2 .940 O.D. x .510 I.D. (2)

Backing Plate Shaft Stage I: 18-500-4 (3)

Set Screws: H-416B 1/4-20x1-1/4 (3)

Button Head: H-839S 1/4-20x1/2 (3)



602-011 - 2000-2017 TWIN CAM (For Cable Style Excludes Throttle-By-Wire)

Throttle Body Gasket: 18-500-5 (1)

Breather Bolts: 18-500-10 (2)

O-Rings: H-024-4 (4)

Washers: H-023-2 .940 O.D. x .510 I.D. (2)

Backing Plate Shaft Stage I: 18-500-4 (3)

Set Screws: H-416B 1/4-20x1-1/4 (3)

Button Head: H-839S 1/4-20x1/2 (3)



602-008 - 88-UP XL SPORTSTER

Throttle Body Gasket: 18-500-5 (1)

Breather Bolts: 18-492-3 (2)

Big Sucker Spacers: 18-492-2 (1)

Washers: H-023-2 .940 O.D. x .510 I.D. (2)

Banjo Bolt O-Ring: H-024-4 (4)

Washers: H-363S .925 O.D. .322 I.D.

Backing Plate Shaft Stage I: 18-500-4 (3)

Set Screws: H-416B 1/4-20x1-1/4 (3)

Button Head: H-839S 1/4-20x1/2 (3)

Button Head: H-686C 5/16-18 x 1-1/2  (3)





602-010 - 1999-2001 FUEL INJECTED

Throttle Body Gasket: 18-498-1 (1)

Banjo Bolt: 18-500-3 (2)

Backing Plate Shaft: 18-500-4 (4)

Washers: H-023-2 .940 O.D. x .510 I.D. (2)

Banjo Bolt O-Ring: H-024-4 (4)

Set Screw: H-414B 1/4-20x1 (4)

Button Head: H-839S 1/4-20x1/2 (4)



602-009 - 1993-1999 EVO

Throttle Body Gasket: 18-500-5 (1)

Banjo Bolt: 18-505-2 (2)

Backing Plate Shaft: 18-500-4 (3)

Washers: H-023-2 .940 O.D. x .510 I.D. (2)

Banjo Bolt O-Rings: H-024-4 (4)

Set Screw: H-414B 1/4-20x1 (4)

Button Head: H-839S 1/4-20x1/2 (4)
